NSD Varicam VS-5E Series User Manual

3.
Outer Dimensions
3-1.
Controller Outer Dimensions
●
VS-5E (VS-5E-1 model has same dimensions.) Unit: mm
130
85
5
120
5
LINE
100VAC
GND
VARICAM
71
5
5
86
81
(85)
120
71
Mounting Hole
1 : 2
2-M4
SWITCH OUTPUT
SENSOR/SERIAL
SWITCH
POSITIONDOG
SWITCH
SENSOROFFONSETCUR.NOR.
0.5
VS-5E
ON
OFF
SET
RUN
SET
TEACH
CLEAR
INIT
●
VS-5ED (VS-5ED-1 model has same dimensions.)
5
5
LINE
100VAC
GND
VARICAM
5
5
2-M4
BCD OUTPUT
SWITCH OUTPUT
SENSOR/SERIAL
BCD/SWITCH
POSITION
PROGRAM
DOG
SWITCH
SENSOROFFONSETCUR.EXT. NOR.
0.5
VS-5ED
ON
OFF
SET
RUN
SET
TEACH
CLEAR
INIT
130
120
86
81
85
71
(85)
120
71
Mounting Hole
1 : 2
Note: The VS-5E-1, VS-5ED-1, and VS-5EX-1 operation panel inscriptions appear in both in English and Japanese.
●A-9●
