NSD Varicam VS-5E Series - Extension Cable Outer Dimensions; External Cable Outer Dimensions

3-3.
Extension Cable Outer Dimensions
●
3P-S-0102-L and 3P-RBT-0102-L Unit: mm
3-4.
External Cable Outer Dimensions
●
VS-C05-L
Note: Dimension L is given in terms of meters.
●A-14●
(42)
(42)
φ8
M14
φ16
R04-JB9F8.0A
φ11 φ16
R04-PB9M8.0A
Note: Dimension L is given in terms of meters.
L±50
69.48
FCN-367J040-AU/F
