9-2.
Designating The Switch Output Settings
9-2-1.
Setting The Switch Outputs by The TEACH Function
Set the key-switch to the TEACH position.
Select the desired Program No.
PROGRAM
Select the desired switch No.
01
 SWITCH
Press the POSITION key.
The current position value will be displayed.
Move the machine to the desired ON position.
The current position value will be displayed.
POSITION
Press the [SET] key.
The ON position setting is registered.
SET
SETSET
SET
125
NOR. CUR. SET ON OFF
SENSOR
SET
TEACH
CLEAR
INIT
RUN
C-14
