Applicable Model
Initial No.
Item Description Setting
VS-5E VS-5ED VS-5EX
Setting
Procedure
page No.
９４
Output status in
SET mode
Select the output status, which is to
exist when the key-switch setting is
changed from the RUN mode to
another mode.
- If the “output HOLD” status is
selected, the status, which existed
just prior to switching from the
RUN mode, will be maintained.
- The current position value output
will not be held.
Output OFF: [0]
Output HOLD: 1
○ ○ ○
９３
Timing pulse Designate the number of pulses to
be output per revolution.
360: [0]
180: 1
60: 2
○ ○ ○
９２
Setting Change
during
operation
This setting determines whether or
not switch output settings can be
changed during operation. If an
“enabled” setting is designated,
setting values can be changed in 0.5
degree units during operation.
Setting changes during operation are
impossible for the VS-5EX Model
when in the “external origin set”
mode.
Change disable: [0]
Change enable: 1
○ ○ ○
９１
Latch pulse
cycle
Designate the latch pulse cycle for
the current position output. A
changeable latch pulse cycle format
is used in order to facilitate easy
reading of the current position
value.
0.352ms: [0]
17.6ms: 1
35.2ms: 2
○ ○
８９
Communication
setting
This setting is required when setting
are to be designated by a
communication format.
- All settings, including initial
settings, can be designated by a
communication format.
- This setting will be invalid if the
key-switch setting is changed form
the INIT mode to another mode.
Setting disabled: [0]
Setting enabled: 1
○ ○ ○
８１
Communication
baud rate
This setting is required when the
communication format is used.
9600bps: [0]
4800bps: 1
2400bps: 2
○ ○ ○
７８
Display output
logic
Designate the desired output logic
for the Current Position or the Speed
output.
Positive logic: [0]
Negative logic: 1
○ ○
０４
Display content Switching between a “current
position BCD output” and a “speed
binary output” is possible.
Current position BCD: [0]
Speed Binary: 1
○
9-1-2
Note: If the key-switch is set to the INIT position, Initial No. “00” will be displayed.
