OPERATION 8. HOW TO USE APPLIED FUNCTIONS (PARAMETER)
● Serial communication parameter (4/4)
No. Name Description and setting range
89
Communication
setting
Designates this function when writing data to VARICAM by
communication.
0: Setting disabled 1: Setting enabled
○ ○ ○ 8-13
86
Node number
Designates this function when “9 (VARIMONI)” is selected at
the parameter No. 85.
Designates the node number to VARICAM.
Setting range: 0 to 15
○ ○ ○ 8-13
85
Protocol
Selects the communication protocol.
0: NSD
1: MELSEC-A (Bidirectional protocol)
2: MELSEC (MC protocol)
3: OMRON
8: NDP (external display unit)
○ ○ ○ 8-13
84
Device selection
Designates this function when “2: MELSEC (MC protocol) is
selected at the parameter No. 85.
Selects the device of programmable controller.
0: D (Data register)
○ ○ ○ 8-13
83
Device No.
Designates this function when the next protocol is selected at
the parameter No. 85.
- 2: MELSEC (MC protocol)
- 3: OMRON
Designates the first number of selected device.
Setting range: 0 to 9000
○ ○ ○ 8-13
82
Communication
dog No.
Designates this function when the next protocol is selected at
the parameter No. 85.
- 2: MELSEC (MC protocol)
- 3: OMRON
Designates the last dog No. of switch output data which
reading by the programmable controller.
Setting range: 0 to 9
○ ○ ○ 8-13
81
Baud rate
Selects the communication baud rate.
○ ○ ○ 8-13
1: 4800bps
2: 9600bps
3: 19200bps
4: 38400bps
5: 57600bps
Display: 4.8
Display: 9.6
Display: 19.2
Display: 38.4
Display: 57.6
80
Permissible angle
for setting change
during operation
During the operation, the permissible angle is designated
when changing the setting value of the switch output by
communication.
Set "1" at the parameter No.92, and select one of following
protocol at the parameter No.85.
0: NSD
1: MELSEC-A (Bidirectional protocol)
2: MELSEC (MC protocol)
3: OMRON
Setting range: 0.5 to 180.0°
○ ○ ○ 8-13
