Alkaline System Installation
Mounting
1. Secure the filter bracket to the wall of your kitchen cabinet using the
two provided screws.
2. Before connecting the filter check that the o-ring is properly seated
in place.
3. Insert the filter into the bracket and twist clockwise to secure it in
place.
Alkaline System Connections
Notice: Do not plug reverse osmosis system into wall outlet yet
OUTLETINLET
WALL
SCREW
1. Connect the 3/8” tubing coming from the leak detector into the INPUT
connection on the back of the reverse osmosis system. Secure the tubing in
place with a retaining clip.
2. Connect the 1/4” tubing coming from the drain saddle into the DRAIN
connection on the back of the reverse osmosis system. Secure the tubing in
place with a retaining clip.
3. Connect the blue 1/4” tubing to the PURE water connection on the back
of the reverse osmosis system. Connect the other end of the blue 1/4“ tubing
to the INLET of the alkaline filter. Secure both connections with a retaining
clip.
4. Connect the blue 1/4” tubing coming from your faucet to the OUTLET of
the alkaline filter. Secure both connections with a retaining clip.
5. Lastly connect the cord coming from your faucet to the connection on
the back of the system labeled FAUCET.
