Installation
Leak Stop Valve Installation
1. Locate the lowest point within your cabinet or installation
location. Using the included screws, secure your leak stop
valve in this location
2. Locate the 3/8” tubing coming from the feed water
adapter and cut it near the location of the leak stopper.
Connect the end of the tubing coming from the feed water
adapter to the quick connect on the leak stop valve labeled
“in”.
3. Take o the plastic wrap o the leak cartridge and place
it inside the leak stop valve as shown.
4. Turn the leak stop valve switch down to put it in the on
position.
WARNING:
Failure to install Leak Stop Valve will
void Warranty
NOTE:
It may be best to insert the cartridge after
the initial startup is complete
3/8” Tubing
Flow Closed
Position
Flow Open
Position
3/8” Tubing
To Next Page
