With radius correction (G41 or G42), the tools are represented by the following symbols appropriate to the dimensions
of the tool correction used:
Cylindrical cutter
Toroidal cutter
Spherical cutter
Exit from the simulation function
Cancel simulation. ☞
EXIT EXIT
Return to "GRAPHIC - PROGRAMMING" menu (or graphic display parameters page).
