5 - 46 en-938821/2
5.4.3.3 Execution of a Programme Step by Step
A programme can be executed step by step (blocks or parts of blocks) in single step mode to check that the machining
procedure is being performed correctly.
Requirements
Measurement origin setting performed on the axes included in the programme.
No mode being executed. If a mode is being executed, selection of the single step mode is only taken into account
after an interruptible block.
Programme selected as active programme (See 5.4.1.2).
Actions
Select the Mode softkeys. ☞
MODE
Display of the Mode softkeys at the bottom of the screen:
SINGLE MDI DRYRUN SEARCH EDIT TEST MANUAL HOMEAUTO
Select the single mode. ☞
SINGLE
Display of the single mode indicator in the status window (See 3.1.3).
Select a programme execution display page (See 5.4.3.2).
Start programme execution by pressing the "CYCLE" button on the machine
panel.
Display of the "INCYC" indicator in the status window (See 3.1.3).
Execution of the block or part of block.
REMARK If function M997 is programmed, the system operates as though it were in
automatic mode and sequences blocks until it encounters an M998, M999 or M02
function.
At the end of the block, the "INCYC" indicator disappears.
Start execution of the next block by pressing the "CYCLE" pushbutton.
