CNC Operation
en-938821/2 5 - 47
5
5.4.3.4 High Speed Execution of a Programme
A programme can be executed at high speed (maximum speed authorised by the system) in order to check
movements, tool changes, etc.
High speed execution can be performed with the part in place, in which case a programme origin shift (modification
of DAT2, see 5.2.1.4) is required to complete the paths outside the part.
Requirements
Measurement origin setting performed on the axes included in the programme.
No mode being executed. If a mode is being executed, selection of the dry run mode is only taken into account after
an interruptible block.
Programme selected as active programme (See 5.4.1.2).
Actions
Increase the value of the programme origin shift (DAT2), if required.
Select the Mode softkeys. ☞
MODE
Display of the Mode softkeys at the bottom of the screen:
SINGLE MDI DRYRUN SEARCH EDIT TEST MANUAL HOMEAUTO
Select the dry run mode. ☞
DRYRUN
Display of the dry run indicator in the status window (See 3.1.3).
Select a programme execution display page (See 5.4.3.2).
Start the programme execution by pressing the "CYCLE" button on the machine
panel.
Display of the "INCYC" indicator in the status window (See 3.1.3).
Execution of the programme at high speed.
At the end of the programme, the "INCYC" indicator disappears.
Return to the old value of the programme origin shift (DAT2).
