1. Operator control panel
2. Separator
3. Top tank (waste water)
4. Waste water emptying hose
5. Bottom tank (clean water)
6. Deck locking pin
7. Brush deck
8. Handle position lever
9. Vacuum switch
10. Pump switch
11. Power Light
12. On / Off Switch
13. On / Off lever
14. Clean water tank ll point
15. Floor tool vacuum hose
16. Vacuum hose
17. Clean water tank emptying hose & ll level
18. Floor Tool Lifting lever
19. Floor tool retaining knobs
20. Semi parabolic oor-tool
21. Clean Water Filter
22. Brush
Machine Overview
1
3
4
5
6
7
8
10
13
14 15 16 17
18
19
20
21
11
2
22
9
12
13
19
