Numatic TT 4045 - Tipping the Brush Deck; Fitting the Floor Tool

8
Machine Set-Up
Fitting the Floor Tool
The oor tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-off
feature if the oor tool gets snagged, whilst in transit.
Raise the oor tool for transit or lower for cleaning operation using the lifting
handle tted to the back of the machine (Fig 11).
For tting the oor tool blades (See Page 13)
Note:
It is easier to t the oor-tool if the weight of the machine is resting on the brush. Ensure the brush is tted rst.
Fig 11
Fig 10
Fig 9
Fit the oor tool and retain using
the detent pin (g 9).
The lifting strap is held by a
detent pin (Fig 10).
Note:
Raise oor-tool again before driving to the cleaning area
Tipping the Brush Deck
To tip the deck into the down position
(Operating mode). Press in the brush
deck locking bar (Fig 7) and rotate the
brush deck (Fig 8).
To change to brush deck up position,
(Transit mode) simply lift the deck and
the sprung loaded locking bar will active
to hold the deck up.
Fig 8
Fig 7
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS
!
