Rear Facing Setup
Before install, store tether strap.
Move Calf Support to desired installation position
(p.34).
1 - Place Child Restraint rear facing in a
compatible vehicle seat (p.8).
2 - Select desired rear facing recline position 1–5
(BLUE) (p.38).
Loosen and unbuckle Harness and retain with
Buckle Tongue Holders (p.18).
Pivot Cup Holders to USE position to access
Rear Facing Belt Path (p.30). If desired, cupholders
can be removed for easier access to Rear Facing
Belt Path.
3 - Remove Infant Insert, lift lower Seat Cover, and
open Rear Facing True Tension Door (p.24).
Complete installation using your vehicle’s Lap/
Shoulder Belt (p.44), the Lower Anchor Belt (p.46),
or a compatible vehicle Lap Belt (p.48).
If infant’s head falls forward, Child Restraint
must be reclined more. Use Infant Insert with
infants 5–11 lbs (2.3–5 kg) to improve the recline
angle for smaller infants.
1
2
3
43RAVA instructions42 RAVA instructions
