Nuna rava - Forward Facing Installation; Forward Facing Setup

5 4 3
2
1
1
2
3
4
5
Forward Facing Installation
recommended 2 years or older (25–65 lbs)
Forward Facing Setup
Remove Tether from storage location and lengthen
for use (p.36).
1 Place Child Restraint forward facing in a
compatible vehicle seat (p.8).
2 Select desired forward facing recline position
1–5 (RED) (p.38).
Loosen and unbuckle harness and retain with
Buckle Tongue Holders (p.18).
3 Fully raise Head Support, lift Seat Cover, and
open Forward Facing True Tension Door (p.24).
Complete installation using your vehicle’s Lap/
Shoulder Belt (p.52), the Lower Anchor Belt (p.54),
or a compatible vehicle Lap Belt (p.56).
OR
vehicle belt & tether strap
Tether strap should always be
used in Forward Facing Installation.
lower anchor belt
5 lbs
(2.3 kg)
50 lbs
(22.6 kg)
25 lbs
(11.3 kg)
35 lbs
(15.8 kg)
40 lbs
(18.1 kg)
11 lbs
(5 kg)
65 lbs
(29.4 kg)
1
2
3
50 RAVA instructions 51RAVA instructions
