Operating Instruction and Documentation
MCS 7500 Flex (Bluetooth)
- 12 -
4.Safety regulations
When using automotive lifts the German safety regulation BGG945: Examine of automotive-lifts;
BGR260 Using automotive-lifts; (VBG14) must be observe adhered to.
Especially the following regulations are very important:
• The max. capacity of one mobile column lift is 7500 kg.
• The mobile column lifts must be completely below, before lifting the vehicle.
• During working with the lift the operating instructions must be followed.
• Only trained personnel over the age of 18 years old are to operate this lift.
• It’s not allowed to transport passengers on the lift or in the vehicle.
• It’s not allowed to climb onto the mobile lift or onto a lifted vehicle.
• The mobile column lift must be checked from an expert after changes in construction.
• It’s not allowed to start with operations at the lift before the main switch is switched off.
• During lifting or lowering the vehicle it must be observed from the operator.
• It’s not allowed to install the standard-mobile column lift in hazardous location or washing
halls.
• Check the center of gravity of the vehicle if heavy parts are removed.
5.Operating instructions
The Safety Regulations must be observed during working with the automotive lift.
Read the safety regulations in chapter 4 carefully before working with the lift!
5.1 Positioning of the columns
• Every solid surface is suitable as installation-place.
• Push the lever from the „neutral“ position to the „lifting“ position.
pic 1: Hand lever
A - Move the hand lever several times in arrow-direction =
The mobile column lift raise.
• Place the columns shown in picture below. Take care, that the antennas are inside of
vehicle area (antennas between vehicles axles; therefore 2 right columns and 2 left
columns.); necessary to improve the radio connection quality.
