Nussbaum MCS 7500 - 6.3 Reset the MCS after an emergency lowering

Operating Instruction and Documentation
MCS 7500 Flex (Bluetooth)
- 23 -
Observe the complete emergency lowering process.
Do not work with the lift until the defective parts are changed.
You can only work again with the automotive-lift, if it is in a safety-related perfect
condition.
• After it, carry out an reset as described in the operating instruction.
6.3 Reset the MCS after an emergency lowering
A reset of the system can be enforced, if the MCS are in the lowest position.
An access on the DIP-Switch can take place only with a switched off main switch and
only through instructed, authorized technical personnel.
a) Drive the vehicle out the lift.
b) Open the cover of the operating unit.
c) Move the DIP switch 7 on position “on” (see pic. 18, Pos 2)
d) After it, move the DIP switch 7 on Position “off” agein.
e) The system has now the normal function again.
f) Close the cover of the operating unit.
pic 18: controller
