25
Technical Data
USB A Port USB port is for ash drive use only. Some ash drives may not be
compatible with the T6 USB port. Do not connect external devices to this
port with USB cables.
USB C Port Connection for service only.
Ethernet Port Connection for local network only. Do not connect the T6 to internet.
Use port to connect to IEC 60601-1 compliant equipment only. Use IEC
60601-1 compliant in-line network isolator when connecting to non-medical
equipment.
3.5 mm Audio Jack Connection for passive earphones and headphones with 3.5 mm male jack
only.
Wireless Connectivity Bluetooth® wireless technology
Standards ANSI/AAMI ES60601-1, CAN/CSA-C22.2 No. 60601-1, IEC/EN 60601-1,
IEC/EN 60601-1-2, EN 20957-1, EN 957–8 Class SB
Marks
Eddy current resistance system The T6 features a speed dependent eddy current resistance system that is
dependent on workload level selected, the user step rate and the user step
length.
Range: 0 - 1400 watts
Stepping Action The T6 features dependent stepping action with up to 8.5” (22 cm) stepping
range.
Watts Testing Parameters Displayed watt values represent the energy consumption rate of the user.
They are calculated in real-time utilizing an algorithm based on mechanical
parameters of the machine and a measured average ride style. The
signicant mechanical parameters that inuence the displayed watt values
include the inertia of the machine’s moving components, the load level
selected by the user, and the rotational velocity of the eddy current disk.
Validation testing of the displayed watt values was performed by comparing
said value and the actual measured mechanical power produced by multiple
users. Displayed watt values are independent of any physiological or
anatomical parameter possessed by the user.
AC Adapter Model (AUTEC POWER SYSTEMS DT-M090-240-U-NSP)
Output
24V dc @ 3.75A 90W Max.
Input
100-240V~50-60Hz, 1.2-0.5A
