SECTION 2
TECHNICAL SPECIFICATIONS
2.1 TECHNICAL SPECIFICATIONS TABLE
NF 800
NF 800 R
Max Speed
RA 200 rotor: 4.100 rpm, RS24 rotor: 14.000 rpm
Max. RCF
RA 200 rotor: 3.045 x g, RS24 rotor : 18.405 x g
Max. Capacity
RA 200 rotor: 4x 200 ml, RS 24 rotor : 24 x 1.5/2 ml
Control System
Microprocessor controlled
Display
High Visibility Digital
No. of Memories
10
Speed Range
500-14000 rpm
Speed Step
10 rpm
Speed Accuracy
± 20 rpm
Timer Range
01-99 min + Hold Position
Timer Step
1 min
Acceleration Rate
0: Slowest 9: Fastest
Braking Rate
0: Slowest 9: Fastest
Power supply
230 V, 50 Hz
Temp. range
-9° C / 40 ° C
Refrigerant Liquid
R134a
Temp. Accuracy
1°C
Temp. Performance
Limited to ambient temperature +12°
C at max speed
+4°C at max. speed
Max. Power
500 W
800 W
Ext. Dimension
455 x 545 x 400
770 x 555 x 400
Packing Dim.
590 x 520 x 490
870 x 650 x 550
Net / Gross Weight
42 / 46 Kg
75 / 80 Kg
2.2 ACCESSORIES FOR NF 800 / 800R
 A 08 062
Puller for rotor removal
 B 50 013
RA 200 swing- out rotor 4*200 ml , 4.100rpm , 3.045 x g
 G 51 026
Set of 4 buckes for RA 200
 G 51 033
Set of 4 buckets with sealing cap
 G 51 032
Set of 4 200 ml PP bottles with cap
 G 51 031
Set of 4 insert 1x100 ml
 G 51 030
Set of 4 inserts 1x50ml conical
 G 51 028
Set of 4 inserts 7x15 ml
 G 51 029
Set of 4 inserts 3x15 ml conical
 G 51 027
Set of inserts 7x5/7 ml
 B 50 015
RS 450 Angle rotor 30x15ml 4.100 rpm 3.007xg
 G 03 012
Adaptor for 1.5 / 2 ml tubes
(Should be ordered according to the capacity of the rotor)
 G 03 014
Adaptor for 13 x 100 mm vacuumed / non - vacuumed rotor
(Should be ordered according to the capacity of the rotor)
