34 Chapter 1 Read this first
Loading Roll Media
12. Pull out the leading edge of the roll media keeping both left and right sides level, and
insert the media into the paper feed slot (d), and feed the paper until it reaches the
paperweight (e).
[85]
Once the media reaches the paperweight, it is automatically fed through to the
platen.
13. Close the ejection guide.
[86]
14. Grasp the center of the leading edge of the media and lift up the release lever.
[87]
e
d
To Next Page
