Oce CS2044 - Removing the Packing Material

20 Chapter 1 Read this first
Removing the Packing Material
Removing the Packing Material
1. Removing the tape and packing material that is attached to the printer body.
[52]
2. Open the top cover.
[53]
3. Lift up Release Lever (a) and remove the protective sheet (b) from the Platen, then
lower the Release Lever.
[54]
a
b
