Adesys bv, Wateringen, NL
Installation instructions
Octalarm-T2 / T4 / T8 / T16
33
does not allow for alarm diallers to automatically check the calling credit status. Running out of
credit will result in the alarm system being blocked!
îî
The Octalarm has numerous different alarm protocols, some of which are not yet supported by all
network providers. See the
GSM enclosure
provided for an up-to-date list.
16.8 Connecting the COM port
The COM port is designed in accordance with the V.24 / RS-232 standard, and provides the following
signals:
PIN nr Name In / Out Description
2 TXD in Transmit Data
3 RXD out Receive Data
4 RTS in Request To Send
5 CTS out Clear To Send
6 DSR out Data Set Ready
7 GND - Ground
8 CD out Carrier Detect
20 DTR in Data Terminal Ready
