Adesys bv, Wateringen, NL
Installation instructions
Octalarm-T2 / T4 / T8 / T16
49
19. TECHNICAL SPECIFICATIONS
Number of inputs 2, 4, 8 or 16
Input contacts: normally open or normally closed, potential-free,
contact power 1mA, open charge 5V.
Amount of call numbers: 10, at max. 16 digits per number
Dialling default analogue: tone code or pulse code
Dialling default ISDN Euro ISDN
(model–I)
Mobile network 900 / 1800Mhz
(model–G)
Outputs: open-collector, max. 150mA, with shared power supply 10 to 15Vdc
(nominal 12Vdc), short-circuit protected
RS-232 port: 25-pole female sub-D, connections in accordance with standard DCE,
at which connected:
signal pin input/output
RXD 2 input
TXD 3 output
RTS 4 input
CTS 5 output
DSR 6 output
GND 7 -
CD 8 output
DTR 20 input
RI 22 output
Baud rate: 19.200 baud,
Power supply: 205-245Vac, 50-60Hz
Power consumption: 4-9 Watt
Emergency power supply: maintenance- free lead battery 12V/ 1.2Ah
Back up emergency power
supply:
3.5 up to 15 hours, dependent on the externally connected alarm
devices
Length of power cable: approx. 1.7 m
Length of telephone cable: approx. 2 m
Size: 255 x 171 x 58 mm
Weight: 1.9 kg
Max. temperature for usage: -5 to +50 C
