OCULUS Pentacam AXL User Manual

13 Test measurement with the Pentacam® AXL
58 / 85 Instruction Manual Pentacam® AXL (G/70100/EN 1121 Rev04)
 Use the Allen key to attach the test eye to the chin and head rest,
directly underneath the retainer for the head rest.
 Make sure that the test eye is in park/home position when it is not
being used.
Fig. 13-1: Attach the test eye
Fig. 13-2: Test eye in park/home position
