Engine coolant level verification
!WARNING
Check coolant level with engine cold.
1. Place vehicle on a level surface.
2. Observe the height of the coolant from
Car’s outer body, it is no need to increase
the coolant if the liquid level between FULL
and LOW.
NOTE:
Coolant level can be checked by looking
at the side of the coolant expansion tank.
3. If the height of the coolant is under LOW,
please add the coolant.
（1）Open the hood upper cover.
（2）Rotate the auxiliary radiator cover left to
make it open.
（3）Put a funnel on auxiliary radiator inlet
in case the coolant overflow .Don't be
too full and the highest position to
the "FULL".
（4）Screw the auxiliary radiator cover
to the right.
（5）Re-install the hood upper cover.
1. Auxiliary radiator 2. Auxiliary radiator cover
