5.4 Weights and measures sealing
Before this product can be used in legal-for-trade or legally controlled
applications, it must be inspected in accordance with local weights and
measures or approval agency regulations. It is the responsibility of the
purchaser to ensure that all pertinent legal requirements are met. Please
contact your local weights and measures office or authorized
manufacturer’s representative for further details.
After a weights and measures official has tested and approved the scale, it
must be sealed by installing the security plate with the security screw.
Replace the bottom cover and secure with the cover screws.
Paper SealPaper Seal
Paper SealPaper Seal
Paper Seal
A paper seal may be placed over one of the screws at the back of the scale
underneath one foot.
Replace the four feet and turn the scale over.
Lead Wire SealLead Wire Seal
Lead Wire SealLead Wire Seal
Lead Wire Seal
For regions requiring a lead wire seal, there are 2 cross drilled screws at
the rear of the scale. The screws can be used in the location as supplied or
as an alternate, one screw can be used to replace one of the counter-sunk
screws at the front of the scale. (Under the leveling feet on small size
Ranger Scales.)
High Capacity Scale
On high capacity scales, remove the existing seal and six cover screws from
the bottom of the scale. You will have to unscrew the feet to access the
screws.
Position the scale so the bottom is accessible.
NOTE: Do the next step carefully.
First, press and hold the unlock switch then, briefly press the ON/ZERO
OFF
switch at the same time, release the unlock switch after the segment test is
displayed. The menus are now unlocked and settings can be changed.
UNLOCK SWITCH
5.3 Unlocking the menus (Cont.)
SEAL
LOW CAPACITY SCALE
HIGH CAPACITY SCALE
PAPER SEAL
LOCATION
PAPER SEAL
LOCATION
LEAD WIRE SEAL
LOCATION
LEAD WIRE
SEAL
