4
Scale
1 Keypad
2 Function keys
3 Display
4 Scale specifications
5 Weighing pan
6 Power cord
7 Power cord with AC Adapter (Scale with internal
battery optional)
8 Adjustable feet
Rear of scale
9 Jack for AC Adapter (battery)
10a Serial # label (Europe)
10b Serial # label (USA) under weighing platform
11 Hole for antitheft device
12 Spirt level (available on certain models only)
13 RS232 Interface (Optional)
14 RS232 Interface (Standard)
Display
15 Stability indicator
16 Active interface (for menu mode)
17 Active scale (in 2-scale systems)
18 Weighing range display (for dual range scales)
19 Symbols for net/gross weight
20 Battery discharge status (optional battery)
21 Weighing unit
22 Number of user selected reference pieces
23 Weighing range bar graph
24 Center of zero
Function keys
25 Clear APW and return to weighing.
26 Average Piece Weight - one piece reference is
displayed for 3 seconds.
27 If two scales are connected, this button switches
the display between the host scale and the
remote scale. Tare, Zero and G/N/T buttons
functions are active for the scale being displayed.
28 Switching from Weighing to Counting Mode.
29 Ten pieces sample size/ 10 pieces on the scale.
30 Continuous press - scrolls through 5, 15, 20, 25,
30, 50 and 100 pieces - sample size.
Short press - take sample size as indicated on
the display.
