72 Model 5380 PFPD Operator’s Manual
Rev. 3.1
Go to the Events menu and select Set Timed Events to access the Timed
Events screen. Enter in the start time, select Record from the Event list box,
and enter in the stop time (relative to the start of a GC run). Click on Add.
Click on OK to save the timed events. WinPulse is now programed to begin
recording at the specified times. See “Timed Events Screen” in Chapter 3 for
more information.
Note: WinPulse files tend to become large very quickly. To minimize the size of
the WinPulse files, go to the Utilities menu and and select Set Prefer-
ences. Set the maximum data file size for a run. The data file is automati-
cally closed when the maximum limit for the data file is met.
