6. Procedures for Repairing
43984801TH Rev.1
117 /
Oki Data CONFIDENTIAL
Contact
Charging roller
Earth (Drum)
Cleaning roller
Developing roller
Toner supply roller
E
D
B
C
A
Figure 6-3
