7. Connection Diagram
43984801TH Rev.1
126 /
Oki Data CONFIDENTIAL
• CN2S Connector Pin Allocation
(Connection to RAM-DIMM)
Pin No. I/O Signal Function
1 1 I VREF Reference Power Voltage
2 2 I VREF Reference Power Voltage
3 3 C VSS Logic Ground
4 4 C VSS Logic Ground
5 5 O DQ0 Data Bus 0
6 6 O DQ4 Data Bus 4
7 7 O DQ1 Data Bus 1
8 8 O DQ5 Data Bus 5
9 9 O VDD Logic Power
10 10 O VDD Logic Power
11 11 O DQS0 Data Strobe 0
12 12 O DM0 Data Mask 0
13 13 O DQ2 Data Bus 2
14 14 O DQ6 Data Bus 6
15 15 C VSS Logic Ground
16 16 C VSS Logic Ground
17 17 O DQ3 Data Bus 3
18 18 O DQ7 Data Bus 7
19 19 O DQ8 Data Bus 8
20 20 O DQ12 Data Bus 12
21 21 O VDD Logic Power
22 22 O VDD Logic Power
23 23 O DQ9 Data Bus 9
24 24 O DQ13 Data Bus 13
25 25 O DQS1 Data Strobe 1
26 26 O DM1 Data mask 1
27 27 C VSS Logic Ground
28 28 C VSS Logic Ground
29 29 O DQ10 Data Bus 10
30 30 O DQ14 Data Bus 14
31 31 O DQ11 Data Bus 11
32 32 O DQ15 Data Bus 15
33 33 O VDD Logic Power
34 34 O VDD Logic Power
35 35 O CK0 Clock 0
36 36 O VDD Logic Power
37 37 O CK0N Clock 0
38 38 C VSS Logic Ground
39 39 C VSS Logic Ground
40 40 C VSS Logic Ground
41 41 - NC Not Connected
42 42 - NC Not Connected
43 43 - NC Not Connected
44 44 - NC Not Connected
45 45 O VDD Logic Power
46 46 O VDD Logic Power
47 47 - NC Not Connected
48 48 - NC Not Connected
49 49 - NC Not Connected
50 50 - NC Not Connected
51 51 C VSS Logic Ground
52 52 C VSS Logic Ground
53 53 - NC Not Connected
54 54 - NC Not Connected
55 55 - NC Not Connected
56 56 - NC Not Connected
