Oki B430 User Manual

7. Connection Diagram
43984801TH Rev.1
129 /
Oki Data CONFIDENTIAL
Pin No. I/O Signal Function
177 177 - NC Not Connected
178 178 - NC Not Connected
179 179 O VDD Logic Power
180 180 O VDD Logic Power
181 181 - NC Not Connected
182 182 - NC Not Connected
183 183 O DQS7 Data Strobe 7
184 184 O DM7 Data Mask 7
185 185 C VSS Logic Ground
186 186 C VSS Logic Ground
187 187 - NC Not Connected
188 188 - NC Not Connected
189 189 - NC Not Connected
190 190 - NC Not Connected
191 191 O VDD Logic Power
192 192 O VDD Logic Power
193 193 I/O SDA EEPROM Serial Data
194 194 O SA2 Logic Ground
195 195 O SCL EEPROM Serial Clock
196 196 O SA1 Logic Ground
197 197 O VDDSPD EEPROM Power
198 198 O SA0 Logic Ground
199 199 - NC Not Connected
200 200 - NC Not Connected
