4. ADJUSTMENT
43984801TH Rev.1
82 /
Oki Data CONFIDENTIAL
CH V MAX CH V MAX -2
0 * -1
0
CH V MIN CH V MIN -1
0 * 0
+1
+2
TR1 CRNT TR1 CRNT -3
0 * -2
-1
0
+1
+2
+3
0X MODE 0X MODE ENABLE
ENABLE * DISABLE
0X TC 0X MODE AUTO
AUTO * FIX
0X TP 0X MODE AUTO
AUTO * FIX
0X ADJST 0X ADJST 0
0 * +1
+2
+3
+4
+5
+6
+7
-1
-2
-3
-4
-5
-6
-7
Press Key
“SETTING”
Press Key
“SETTING”
Press Key
“SETTING”
Press Key
“SETTING”
Press Key
“SETTING”
Press Key
“SETTING”
Press Key
“SETTING”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Select by
Key “SETTING”
and press key
“MENU▲”
“MENU▼”
Maximum CH voltage offset
Minimum CH voltage offset
Current value converting of TR1_I at
TR resist lead
[A/C Zero Cross Phase Control ENABLE/DISABLE]
Select whether operate phase control.
TC fixed mode: Use fixed value
Use 50Hz or 60Hz that is judged by the calculated
value.
TC varied mode: Use calculated value
[TP Fixed/Varied selection]
Select TP value (Zero Cross signal pulse width) that
is used for parameter calculating of phase control.
TC varied mode: Use calculated value
TP fixed mode: Use fixed value (1ms)
[ON DELAY OFFSET]
At setting HEATON Signal Output Time, set the
value that the corresponding table value has been
added to the resister.
0: 0.0ms
1: 0.5ms
2: 1.0ms
3: 1.5ms
4: 2.0ms
5: 2.5ms
6: 3.0ms
7: 3.5ms
-8: -4.0ms
-7: -3.5ms
-6: -3.0ms
-5: -2.5ms
-4: -2.0ms
-3: -1.5ms
-2: -1.0ms
-1: -0.5ms
[TC Fixed/Varied selection]
Select TC value (Zero Cross signal period) that is
used for parameter calculating of phase control.
