Control Codes: HP PCL5e • 19
ESC * c # Q 1B 2A 63 # 51 27 42 99 # 81 Pattern Control
ESC * c # R 1B 2A 63 # 52 27 42 99 # 82 Specify Symbol Set ID Code
ESC * c # S 1B 2A 63 # 53 27 42 99 # 83 Symbol Set Control
ESC * c # V 1B 2A 63 # 56 27 42 99 # 86 Vertical Rule/Pattern Size by Decipoint
ESC * c # W [data] 1B 2A 63 # 57 [data] 27 42 99 # 87 [data] User-Defined Pattern
ESC * c # X 1B 2A 63 # 58 27 42 99 # 88 Horizontal Picture Frame Size
(Decipoints)
ESC * c # Y 1B 2A 63 # 59 27 42 99 # 89 Vertical Picture Frame Size
(Decipoints)
ESC * c O T 1B 2A 63 30 54 27 42 99 0 84 Set Picture Frame Anchor Point
ESC * p # R 1B 2A 70 # 52 27 42 112 # 82 Set Pattern Reference Point
ESC * p # X 1B 2A 70 # 58 27 42 112 # 88 Horizontal Cursor Position by PCL Unit
ESC * p # Y 1B 2A 70 # 59 27 42 112 # 89 Vertical Cursor Position by PCL Unit
ESC * r # A 1B 2A 72 # 41 27 42 114 # 65 Start Raster Graphics
HP PCL5e Control Codes (continued)
ASCII Hexadecimal Decimal Function
