Control Codes: HP PCL5e • 20
ESC * r # F 1B 2A 72 # 46 27 42 114 # 70 Raster Graphics Presentation Mode
ESC * r # S 1B 2A 72 # 53 27 42 114 # 83 Raster Width
ESC * r # T 1B 2A 72 # 54 27 42 114 # 84 Raster Height
ESC * r B 1B 2A 72 42 27 42 114 66 End Raster Graphics
ESC * r C 1B 2A 72 43 27 42 114 67 End Raster Graphics and Compression
mode
ESC / t # R 1B 2F 74 # 52 27 47 116 # 82 Raster Density
ESC * s # I 1B 2A 73 # 49 27 42 115 # 73 Inquire Status Readback Entity
ESC * s # T 1B 2A 73 # 54 27 42 115 # 84 Set Status Readback Location Type
ESC * s # U 1B 2A 73 # 55 27 42 115 # 8 Set Status Readback Location Unit
ESC * s # X 1B 2A 73 # 58 27 42 115 # 88 Echo
ESC * s 1 M 1B 2A 73 1 4D 27 42 115 1 77 Free Space
ESC * t # R 1B 2A 74 # 52 27 42 116 # 82 Raster Graphics Resolution
ESC * v # N 1B 2A 76 # 4E 27 42 118 # 78 Source Transparency Mode
HP PCL5e Control Codes (continued)
ASCII Hexadecimal Decimal Function
