10 1 Basic Operations
Internal View
No. Name Description
1 Paper stopper Raise this when printing on paper larger than Letter/A4 size.
2 Drum/toner cartridge Contains the toner and the photosensitive drum.
3 Cover A Open this when replacing the drum/toner cartridge and removing
jammed paper.
4 Fuser unit Fixes the toner on the paper. Do not touch this when using the
printer as it is hot.
5 Transfer roll cartridge Transfers the toner image on the surface of the photosensitive
drum to the paper.
6 Cover B Open this when removing jammed paper.
1 2 3 5 4 6
