1.1 Main Components and Their Functions 11
Control Panel
No. Name Description
1 <MENU> button Press to move to menu operation.
2 <FEED/SELECT> button Press to set the menu candidate values. Use this to print report/
list also.
3 <READY> indicator When the light is on, the printer is ready to receive data from the
computer.
4 LCD display Displays the setting items, machine status, and messages.
Refer to
• “Display” (P. 12)
5
<A
TTENTION> indicator
When the light is on, there is
a malfunction in the pri
nter
.
indicator
Press to enter and exit the power saver mode. The light is on
when the machine is in the power saver mode.
7 <CANCEL> button Press to cancel printing.
8 <ON LINE> button Press to enter the offline status. When in the offline status, the
machine cannot receive data or process printing. Press again to
exit the offline status and enter the online status (where the
machine can receive data from the computer).
9
<> <> <> <>
buttons
Press these to move to the required menu, item and candidate
value on the display. Also, press the < > button when you are
doing secure/proof/delayed printing or when you are checking/
printing received mails manually.
Note
• When you are changing the candidate values by the < >
< > buttons, you can press and hold down the buttons to
change the display continuously. Also, pressing the < > < >
buttons simultaneously will display the default values.
6
789
12
354
To Next Page
