Oki B930dn User Manual

B930n User’s Guide> 45
C USTOM S IZE P APER
You can print custom size from Trays 1 through 5. Tray 6 only prints
standard paper. The following paper size ranges can be printed from
each tray:
NOTE
> When loading custom size paper in the trays load by the
correct edge (long or short) and to adjust the paper
guides as necessary. See “Loading Paper” on page 29 for
instructions on loading paper into each tray.
The most convenient way to enable this feature is by using your
Printer Properties. You may also enable this feature at the Operator
Panel or by using the EWS.
To load and print custom paper:
1. Load the media in the desired tray.
2. Change media type at Operator Panel via that tray’s Media
Menu option.
3. Select the Paper Feed button in the Setup tab within your
Printer Properties.
The Paper Feed Options window appears.
4. Select Custom Size.
5. Enter the paper parameters and name.
6. Click Add.
INPUT TRAY OUTPUT TRAY
5 1-4 STANDARD STACKER
UPPER
STACKER
LOWER
Width 89 - 297
mm
(3.5 -
11.70 in.)
140 - 297
mm
(5.5 -
11.70 in.)
89 - 297 mm
(3.5 - 11.70
in.)
203 - 297
mm
(7.9 - 11.70
in.)
203 - 297
mm
(7.9 - 11.70
in.)
Height 98 - 432
mm
(3.87 - 17
in.)
182 - 297
mm
(7.16 -
11.70 in.)
98 - 432 mm
(3.87 - 17.0
in.)
182 - 432
mm
(7.16 - 17.0
in.)
182 - 432
mm
(7.16 - 17.0
in.)

Oki B930dn Specifications

Performance

print speed	50 pages per minute
time to first page	7 seconds
print resolution	1200 x 1200 dpi
CPU	600 MHz
duty cycle	300, 000 pages per month

Memory

standard RAM memory	256 MB
maximum RAM memory	768 MB
bitmapped fonts	47 PCL

Weight and Dimensions

dimensions	20.0" x 25.0" x 21.0" (50.8 cm x 63.5 cm x 53.3 cm)
weight	90.0 lb. (32.1 kg)
paper size	5.8" x 8.3" min. to 11" x 17" max.
