- 121 -
6. Troubleshooting
While setting the fuser unit, be careful not to hit it to the LED head.
13
Tilt the lock levers on the both sides of the fuser unit.
14
Replace the four image drums into the machine
While setting the image drum, be careful not to hit it to the LED head.
15
Close the output tray (a) slowly and push the center of the output tray for
confirmation.
Task is complete.
