- 29 -
2. Setting Up
5
Pass the LAN cable under the tab, and then close the interface cover.
6
Insert the other end of the LAN cable into the hub.
Go to the procedure to "Loading Paper in the Tray".
A USB cable is not supplied.
1
Prepare a USB cable.
If you want to connect in USB 2.0 Hi-Speed mode, use a Hi-Speed USB 2.0 USB cable.
This machine does not support USB 3.0.
2
Check that the machine and computer are turned off.
3
Open the interface cover on the back side of the machine pressing the center
part of it.
4
Insert one end of the USB cable into the USB interface connector on the
machine.
Connecting a USB Cable
To Next Page
