- 74 -
3. Basic Operations
When this machine turns on, the home screen is displayed on the touch panel.
• Home Screen
The screen image shows the factory default setting. The screen that appears when the machine is turned on and gets
ready to be used can be changed from [Device Settings] > [Admin Setup] > [Manage Unit] > [Default Mode] on the
touch panel.
• Name and Function of the Device Settings Screen
[Basic] tab > [Paper Setup/MP Tray] screen is used as an example.
You can enter a value in the field with displayed by using the numeric keypad.
Name and Functions on the Touch Panel
Item Description
1 Stationary button area Displays buttons that appear on the screen at all times.
Displays the following items.
• [Job Macro]
• [Function Settings]
• [Device Settings]
•[RESET]
• [Logout]
• Antenna mark: appears when the wireless LAN is enabled.
•[ ]
Only available buttons are displayed on the selected menu.
2 Title and operation guide
area
Displays the title of the current screen and provides guide for possible operations.
3 Main area Press to use the print functions.
The following steps and functions are displayed.
• Change Consumable & Maintain
(Toner cartridges, Image drums, Belt units, Fuser units)
• Maintain and Care for the Unit
(Feeder Rollers, LED head)
Item Description
1 Stationary button area Displays buttons that appear on the screen at all times.
Only available buttons are displayed on the selected menu.
2 Title and operation guide area Displays the title of the current screen and provides guide for
possible operations.
3 Main area The current setting is displayed on each button.
<About the mark on a button>
: Indicates that the next page exists.
Item Description
To Next Page
