- 119 -
Replacing Consumables and Maintenance Units
4
4. Maintenance
6 Hold the fuser unit handle (6) and lift
the fuser unit out of the printer.
6
7 Hold the fuser unit handle (6) and place
the fuser unit into the printer.
6
8 Push back the left locking lever (5) of
the fuser unit to lock.
5
9 Close the top cover (4) by pushing the
both sides of the cover rmly.
4
10 Close the front cover (2).
Note
● The front cover cannot be closed if the top cover is
not closed securely.
2
11 Please recycle fuser unit.
Memo
● If you must dispose of a fuser unit, put it in a plastic bag
or similar container and dispose of it in accordance with
your municipality’s ordinances or guidelines.
