Operator Panel
1
1. Setup
Names of Components
1
2
3
4
5
6
7
8
8
No. Name
1 Front cover
2 Front cover open lever
3 Operator panel
4 Power switch
5 Top cover
6 Multipurpose tray
7 Tray 1
8 Air vents
9
10
11
12
13
14
15
No. Name
9 Top cover open button
10 Toner cartridge
Image drum (K: black)
11 Toner cartridge
Image drum (Y: yellow)
12 Toner cartridge
Image drum (M: magenta)
13 Toner cartridge
Image drum (C: cyan)
14 Fuser unit
15 LED head (four heads)
16
17
No. Name
16 Multipurpose tray
17 Paper set cover
18
22
19
20
21
No. Name
18 Faceup stacker
19 AC power socket
20 Interface part
21 Access cover
22 Duplex unit (Only for the model of the name
with dn)
● Interface part
23
24
No. Name
23 USB interface connection
24 Network interface connection
