Oki C8800dn User Manual

C8800 User’s Guide
322
10. Change the slide bar values of gamma, hue, brightness,
and saturation to adjust the color.
Use primary colors of ink
Select this to adjusts the settings to the standard hues for
the printer.
The Gamma slide bar adjusts total brightness.
The Hue/Brightness slide bar adjusts output color.
Use the printer color buttons to switch to a different color.
Brightness
For Brighter color, slide the Gamma bar to the left.
Hue
Adjustments are made relative to positions on the color
wheel.
Move forward = + (counter-clockwise)
Move backward = - (clockwise)
Hue Toner printing
R (Red) 50% yellow and 50% magenta
Y (Yellow) 100% yellow
G (Green) 50% cyan and 50% yellow
C (Cyan) 100% cyan
B (Blue) 50% magenta and 50% cyan
M (Magenta) 100% magenta

Oki C8800dn Specifications

Performance

print speed color	26 ppm
print speed monochrome	32 ppm
time to first page color	10 sec.
time to first page monochrome	9 sec.
processor	500 MHz PowerPC CPU
print resolution	1200 x 600 dpi
duty cycle	75, 000 pg./mo.

Memory

standard memory	256 MB
maximum memory	768 MB
memory storage option	40 GB Hard Disk Drive

Paper Handling

paper input standard	400 sheets
paper input maximum	930 sheets
multi-purpose tray capacity	100 sheets
paper sizes main tray	4.1" x 5.8" to 11" x 17"
paper sizes 2nd tray	5.8" x 8.3 to 8.5" x 14"
paper sizes multi-purpose tray	3" x 5" to 11.6" x 47.24" banner

Supplies

toner cartridge life	6, 000 pages each (CMYK)
image drum life	20, 000 pages

Weight and Dimensions

size without duplex	19.1" x 23.3" x 13.4"
size with duplex	19.1" x 25.5" x 13.4"
size with duplex and 2nd tray	19.1" x 25.5" x 19.3"
weight without duplex	76.5 lb. (34.7 kg)
weight with duplex	85.6 lb. (38.8 kg)
weight with duplex and 2nd tray	100.9 lb. (45.7 kg)
