Oki C8800dn User Manual

C8800 User’s Guide
80
Fuser in Situ.eps
2. Locate the fuser (1).
3. Pull the blue fuser lock lever (2) towards the front of the
printer.
4. Hold the fuser by its handle. Lift the fuser out of the
printer. If the fuser is still warm, place it on a flat surface
which will not be damaged by heat. After letting the fuser
cool down, discard it.
5. Remove the new fuser from its packaging. Remove any
packing tape.
6. Push the orange transport lock to the left to release it.
You’ll hear it snap. Remove it.
7. Hold the new fuser by the handle. The fuser pressure
release lever (2) should be on the left. Lower the fuser
into the printer.
Fuser Alone.eps
C
M
Y
K
1
2
2

Oki C8800dn Specifications

Performance

print speed color	26 ppm
print speed monochrome	32 ppm
time to first page color	10 sec.
time to first page monochrome	9 sec.
processor	500 MHz PowerPC CPU
print resolution	1200 x 600 dpi
duty cycle	75, 000 pg./mo.

Memory

standard memory	256 MB
maximum memory	768 MB
memory storage option	40 GB Hard Disk Drive

Paper Handling

paper input standard	400 sheets
paper input maximum	930 sheets
multi-purpose tray capacity	100 sheets
paper sizes main tray	4.1" x 5.8" to 11" x 17"
paper sizes 2nd tray	5.8" x 8.3 to 8.5" x 14"
paper sizes multi-purpose tray	3" x 5" to 11.6" x 47.24" banner

Supplies

toner cartridge life	6, 000 pages each (CMYK)
image drum life	20, 000 pages

Weight and Dimensions

size without duplex	19.1" x 23.3" x 13.4"
size with duplex	19.1" x 25.5" x 13.4"
size with duplex and 2nd tray	19.1" x 25.5" x 19.3"
weight without duplex	76.5 lb. (34.7 kg)
weight with duplex	85.6 lb. (38.8 kg)
weight with duplex and 2nd tray	100.9 lb. (45.7 kg)
