Oki C910 Service Manual

Oki Data CONFIDENTIAL
44043511TH Rev.2
151 /
5.1.2.6 Consummable Parts Counter Display
This self-diagnosis is used to display the consumption status of the consumable parts of the printer.
1. It will go into normal self-diagnosis. Continue to press the [MENU+] and [MENU-]
keys until “CONSUMABLE STATUS” appears at the top row of the display. (The [MENU+]
key to Increment the Test Item / the [MENU-] key to decrement the Test Item.)
2. After the [ENTER] key is pressed, press the [MENU+] and [MENU-] keys to
sequentially display the consumption status according to consumable part.
3. Press the [BACK] key to end the test. (Returns to state 1)
5.1.2.7 Consumable Continual Counter Display
This self-diagnosis is used to display the consumption status of the consumable parts of the
printer.
The life consumption status of consumable parts means that the counter value is not initialized
though the consumable parts are replaced. It is a way to continually count the consumption level
of the consumable parts of the printer.
1. It will go into normal self-diagnosis. Continue to press the [MENU+] and [MENU-]
keys until “PRINTER STATUS” appears at the top row of the display. (The [MENU+]
key to Increment the Test Item / the [MENU-] key to decrement the Test Item.)
2. After the [ENTER] key is pressed, press the [MENU+] and [MENU-] keys to
sequentially display the life consumption status according to consumable part.
3. Press the [BACK] key to end the test. (Returns to state 1)
Top of the Display
Bottom of the Display
Format Detail
K-DRUM UNIT ****** IMAGES DEC Indicates the total number of revolutions since the ID
unit for each color has been installed.
Y-DRUM UNIT
M-DRUM UNIT
C-DRUM UNIT
FUSER UNIT ****** PRINTS DEC Indicates how many pages have been printed since the
fuser unit has been installed.
TR BELT UNIT ****** IMAGES DEC Indicates how many pages have been printed since the
belt unit has been installed.
K-TONER ***% DEC Indicates what quantity of each color of toner has been
consumed.
* Indicates 90% when the toner level is low.
Y-TONER
M-TONER
C-TONER
STAPLE UNIT ****** JOBS DEC Indicates how many times stapling has been performed.
PUNCH UNIT ****** PRINTS DEC Indicates how many times punching has been
performed.
PATTING ROLLER ****** PRINTS DEC Indicates how many sheets have passed by the patting
roller.
STAPLE CONSUMPTION ****** PIECES DEC Indicates how many staples have been used.
* The count is reset when staples are refilled.
STAPLE UNIT REPLACE ****** TIMES DEC Indicates how many times the staple unit has been
replaced.
PUNCH UNIT REPLACE ****** TIMES DEC Indicates how many times the punch unit has been
replaced.
Top of the Display Bottom of the Display Format Detail
K-IMPRESSIONS ****** PRINTS DEC Indicates how many pages have been printed
using each color.
Y-IMPRESSIONS
M-IMPRESSIONS
C-IMPRESSIONS
TOTAL SHEETS FEED ****** PRINTS DEC Indicates the total number of sheets fed.
FINISHER TOTAL PAGE ****** PRINTS DEC Indicates the total number of sheets having
passed by the finisher.
