- 125 -
Matching colors using the control panel
4
3
5
1
2
Convenient print
functions
Appendix Index
Checking and
Changing Printer
Settings Using
the Control Panel
Network
Setup
Matching
Colors
Using Utility
Software
(5)
Specify the number of the pattern
checked in the "Mid-Tone" area,
and press the [OK] button.
(6)
Specify the number of the pattern
checked in the "Dark" area, and
press the [OK] button.
(7)
The pattern number speciîš¿ed in
each area will be displayed.
If the pattern number is correct,
select [Yes], and press the [OK]
button.
Memo
z
To respecify the pattern number select [No] to
return to the "Calibration" screen.
(8)
Select [Return], and press the [OK]
button.
(9)
The display will return to the
standby screen.
Memo
z
If the desired color balance is not obtained even
after implementing [Base Color Tuning], adjust
the CMY color balance watermarks manually
using [Adjusting the color balance]. For color
balance watermark adjustments, see "Adjusting
the color balance" (P.126).
z
If the overall tone is still too bright or too dark
even after implementing [Base Color Tuning],
adjust the black tone manually using [Fine
Color Tuning], and then implement [Basic color
Tuning] again. To brighten the overall tone,
adjust the black tone in [Fine Color Tuning] in
the - direction, and to darken the overall tone,
adjust the black tone in [Fine Color Tuning] in
the + direction.
4
Check the color balance adjustment
results.
(1)
Print the color matching patterns.
(2)
Use the print results for the color
matching pattern to check the
adjusted results.
If the pattern that seems most
similar to the adjacent CMY mixed
colors part and single color K part
in the "Highlight", "Mid-Tone",
or "Dark" areas matches the
"Current" on the left or the color
matching pattern, the color balance
adjustment is complete.
Repeat Steps 1 to 3 according to
the checked results.
To Next Page
