Paper Feed Drive Mechanism
The feed roller [A] is located above the upper tray bottom plate [B], and the friction
pad [C]. It allows only one sheet to feed from the paper tray. They are controlled by
the paper feed clutch [D]. The registration sensor detects the leading edge of the
paper and synchronizes paper feed with the activation of the laser diode to write
the image on the OPC drum.
G182D006.WMF
[A]
[B]
[C]
[D]
