PRINTER MODEL-L1
           （
G191
）
SERVICE MANUAL
TECHNICAL DOCUMENT
2-19
Replacement
Adjustment
2.5.4 DISCHARGE LAMP-ASS’Y REMOVAL
Preparation:
1) Remove Fusing unit. (See Upper Unit Removal).
[A]: Ground Wire-Bracket-Discharge Lamp (1 screws)
[B]: Harness-Discharge Lamp
[C]: Discharge Lamp Assy (2 screws)
[B]
[C]
[A]
[C]
