54 Microline 490/491 User’s Guide
Clearing Paper Jams
Rear-Feed Paper Jams
1 Turn off the printer.
2 Use the platen knob to back the paper all the way out of the
printer.
CAUTION!
Make sure the printer is turned off before you open the access
cover.
3 Open the access cover (1) and remove the pull-up roller
assembly (2). Remove any torn pieces of paper.
4 Lift the sheet guide (1) and reload paper. Make sure you
lock the tractor covers.
5 Lower the sheet guide, then install the pull-up roller
assembly and close the access cover.
6 Turn on the printer and press FF/LOAD.
