72 Microline 490/491 User’s Guide
IBM Proprinter X24e / XL24e and
IBM X24e AGM / XL24e AGM
Commands
IBM Command ASCII Decimal
Backspace BS 8
Cancel CAN 24
Carriage Return CR 13
Character Pitch, Select
10 cpi DC2 18
12 cpi ESC : 27 58
15 cpi ESC g 27 103
Condensed Print ESC SI, or SI 27 15, or 15
Character Style
Normal ESC q 0 27 113 48
Outline ESC q 1 27 113 49
Shadow ESC q 2 27 113 50
Outline with Shadow ESC q 3 27 113 51
IBM Command ASCII Decimal
Double Width
On ESC W 1 27 87 49
Off ESC W 0 27 87 48
for One Line SO 14
Emphasized Printing On ESC E 27 69
Emphasized Printing Off ESC F 27 70
Enhanced Printing On ESC G 27 71
Enhanced Printing Off ESC H 27 72
Form Feed FF 12
Form Length
n inches
n = 1 to 255 ESC C NUL n 27 67 0 n
n lines
n = 1 to 255 ESC C n 27 67 n
Horizontal Tab, Execute HT 9
IBM Character Set
Select Set I ESC 7 27 55
Select Set II ESC 6 27 54
