76 Microline 490/491 User’s Guide
Emulations (co-resident)
• Epson LQ
• IBM Proprinter X24e / XL24e
• IBM X24e AGM / XL24e AGM
Print Speed
Mode Pitch Speed
High Speed Draft (HSD) 10 cpi* 420 cps†
Utility 10 cpi 315 cps
12 cpi 378 cps
15 cpi 472 cps
17.1 cpi 269 cps
20 cpi 315 cps
Letter Quality (LQ) 10 cpi 105 cps
12 cpi 126 cps
15 cpi 157 cps
17.1 cpi 180 cps
20 cpi 210 cps
* Characters per inch
† Characters per second
Characters per Line (cpl)
Setting ML490 ML491
10 cpi 80 cpl 136 cpl
12 cpi 96 cpl 163 cpl
15 cpi 120 cpl 204 cpl
17.1 cpi 137 cpl 233 cpl
20 cpi 160 cpl 272 cpl
Graphics Resolution
360 x 360 dpi maximum (24-dot, hex density)
Paper Thickness: Tractor Feed
Rear Feed: 0.014" (0.36 mm) maximum
Bottom Feed: 0.017" (0.44 mm) max.
Requires optional push or pull tractor.
